Single Phase Meters
LCD
Single-phase LCD meters offer clear and precise energy data, ensuring easy readability for residential and small commercial use. offering unmatched accuracy and efficiency.
Starting Price
₹1,800
Select Variant:
5-30A
5-30A
₹1,800
10-60A
10-60A
₹2,100
Benefits
Advanced metering capabilities
Effortless installation
Durable materials
Energy efficient
Features
High precision readings
Secure data storage
Wide operational temperature range
Instant fault detection
Technical Specifications
Comprehensive technical details
General
| Model Name / Number | SPL-2002 |
| Application | Residential |
| Standards Compliance | IS 13779:2020, IEC 62052-11 |
Electrical
| Voltage Rating | 240V |
| Current Rating | 5-30A/10-40A/ 10-60A |
| Frequency | 50Hz |
| Power Factor | 0 lag - Unity - 0 Lead |
| Accuracy Class | Class 1 |
| Power Consumption | 0.6W |
Measurement
| Energy Measurement | Active |
| Load Profile | No |
| Tamper Detection | Yes |
| Data Storage Capacity | 1 Year |
| Measurement Interval | Not Applicable |
Mechanical
| Dimensions | 150 x 100 x 50 mm |
| Weight | 500g |
| Mounting Type | Wall Mount |
| Enclosure Material | Polycarbonate |
communication
environmental
| Operating Temperature Range | -10?C to +55?C |
| Storage Temperature Range | -20?C to +70?C |
| Humidity | 95% Non-condensing |
| Ingress Protection (Ip) Rating | IP54 |
display and user interface
| Display Type | LCD |
| Display Parameters | Voltage, Current, Power, Energy |
firmware and software
| Data Security Features | Encryption, Secure Boot |
certifications and approvals
| Certifications | ISO 9001, CE, UL |
additional features
| Time-Of-Use (Tou) Tariffs | No |
| Event Logging | No |
| Load Control Relay | No |
| Battery Backup | No |
| Anti-Tamper Features | Yes |
